WAVEGO 12-DOF STEM Education Python Programming Robot Dog Raspberry Pi 4B Facial Recognition Color Tracking Motion Detection
WAVEGO 12-DOF STEM Education Python Programming Robot Dog Raspberry Pi 4B Facial Recognition Color Tracking Motion Detection
WAVEGO, 12-DOF Bionic Dog-Like Robot, Open Source For ESP32 And PI4B, Facial Recognition, Color Tracking, Motion Detection
The WAVEGO is a high-DOF bionic dog-like robot which features 2.3kg.cm large torque servos, reliable structure, and flexible motion, incorporating devices like front camera, 9-axes motion tracker, RGB indicator, etc., together with open source multi-platform Web application. It uses the ESP32 as sub controller for connecting rod inverse solving and gait generation, sharing calculating task for the host controller, an additional Raspberry Pi can be attached as the host controller for high-level decision operating.
Product Features
- Overall 12-DOF, multi connecting rods leg design, increasing the servo effective torque
- A real time operating system is used as sub controller for connecting rod inverse solving and gait generation, sharing calculating task for the host controller and improving the gait solving efficiency
- Ultra compact structure design, allows using on the table, aluminum alloy + nylon structure materials, ensuring strength while keeping it light weight
- Additional Raspberry Pi can beattached as the host controller to enable OpenCV high-level functions, demo codes including facial recognition, motion detection, color tracking, and more. Reserved extension interface for secondary development, along with user manual and secondary development documents.
Selection Guide



High-DOF, More Flexible Motion
Overall 12-DOF, Multi Connecting Rods Leg Design + Inverse Kinematics Algorithm, Significantly Increasing The Servo Effective Torque

Ultra Compact Structure Design
5052 Aluminum Alloy And PA12 Nylon Structure Materials, 40 Sets Of Bearing Joint All Over The Body,
Rugged And Reliable Structure, Ensuring Strength While Keeping It Light Weight

Self-Balancing Posture
Embedded High Precision 9-Axes Motion Tracker ICM20948 Accommodating To Different Terrains, Keeping The Camera Stable By Self-Balancing

5MP 160° Wide Angle Camera*
Allows Using OpenCV-Based Functions Like Facial Recognition, Color Tracking, Motion Detection, And More

Facial recognition

Color tracking
* The 5MP camera is only included in WAVEGO EX and PI4 KIT.
Remote Control Via Web
Auto-Generated WiFi Hotspot On Startup, Needs No Compiling Environment Configuration,
Allows Connecting To And Login The Control Page Via Smartphone Or PC Browser, Without Installing App

Developing High-Level Functions
An Raspberry Pi Can Be Attached As Host Controller To Communicate With The Sub Controller Via UART,
The ESP32 Sub Controller Will Share Lots Of Calculating Task Like Connecting Rod Inverse Solving And Gait Generation, Retaining More Raspberry Pi Performance For Developing High-Level Functions
Developing High-Level Functions


Introduction


Dimensions

Specifications

Weight: 0.722 kg
- The 18650 batteries are NOT included in the unassembled kits.
- Please note that the battery length SHOULD be less than 67mm, some batteries with protection plate in the market are NOT supported.
WAVEGO BASIC
- WAVEGO body case x1
- WAVEGO basic parts x1
- Semi-transparent acrylic panel x1
- Double-sided sticker x1
- WAVEGO base board x1
- 2MP camera x1
- 2.4G antenna x1
- 0.91inch OLED display x1
- Micro thrust bearing x14
- Micro ball flange bearing x30
- USB cable (~1m) x1
- Plus screwdriver x1
- Cross wrench sleeve x1
- IPEX 1 to SMA cable (~17cm) x1
- Jumper wire (~20cm) x4
- 4PIN PH2.0 cable x1
- Servo pack x1
- OPTIONS 8.4V 2A battery charger x1
- Screws and standoffs x1
- Portable bag x1

WAVEGO EX
- WAVEGO body case x1
- WAVEGO basic parts x1
- Raspberry Pi extension holder x1
- 5MP wide angle camera x1
- Cooling fan x1
- Semi-transparent acrylic panel x1
- Double-sided sticker x1
- Micro thrust bearing x14
- Micro ball flange bearing x30
- WAVEGO base board x1
- 2MP camera x1
- 2.4G antenna x1
- 0.91inch OLED display x1
- Plus screwdriver x1
- Cross wrench sleeve x1
- 4PIN PH2.0 cable x1
- IPEX 1 to SMA cable (~17cm) x1
- Jumper wire (~20cm) x4
- USB cable (~1m) x1
- Servo pack x1
- OPTIONS 8.4V 2A battery charger x1
- Screws and standoffs x1
- Portable bag x1

WAVEGO PI4 KIT
- WAVEGO body case x1
- WAVEGO basic parts x1
- Raspberry Pi extension holder x1
- 5MP wide angle camera x1
- Cooling fan x1
- Semi-transparent acrylic panel x1
- Double-sided sticker x1
- Micro thrust bearing x14
- Micro ball flange bearing x30
- WAVEGO base board x1
- 2MP camera x1
- 2.4G antenna x1
- 0.91inch OLED display x1
- USB cable (~1m) x1
- Plus screwdriver x1
- Cross wrench sleeve x1
- Servo pack x1
- IPEX 1 to SMA cable (~17cm) x1
- 4PIN PH2.0 cable x1
- Jumper wire (~20cm) x4
- PI4B-4GB x1
- 16GB micro SD card x1
- Copper heatsink x1
- Card reader x1
- OPTIONS 8.4V 2A battery charger + 5V USB-C power supply x1
- Screws and standoffs x1
- Portable bag x1

WAVEGO READY
- WAVEGO BASIC READY kit x1

RPI WAVEGO ACCE READY
- WAVEGO EX READY kit x1

Tutorial Documentation (click here)
